Types of Woodworking Clamps
When choosing the proper tools, it is vital to consider the kind of work you plan on doing and the type of material you are going to be working with. Various types of clamps can be classified into several basic groups, which differ depending on the material and the technique of use. Each of these types can come in a multitude of varieties and can be used for a lot of purposes outside of their primary intended use.
Woodworking F Clamps
Traditional woodworking F clamps are the most general and widely used kind of clamping device. It’s used by just about every woodworker and is appropriate for any situation in which two items must be clamped together. It’s a perfect addition to any workshop and is useful for projects outside of just woodworking.
F clamps are typically available in lengths running from 150 mm to 1 meter. The jaws have plastic covers for protecting the workpiece from any damages. They provide profiled cast iron arms connected to a steel bar. The handles have a coating with a light but secure silicone layer, referred to as Soft-Grip, to guarantee a better grip throughout use. Additionally, you aren’t going to feel the need for using too much force to stop your hand from slipping, unlike conventional wooden handles.
One-Handed Quick-Release Clamps
Quick-release bar clamps are an excellent device when two hands are simply not enough. It comes convenient for the attaching of individual pieces, to secure materials to the bench, a pillar drill, a device’s guide rail and to other apparatuses, in which you need to handle with just one hand. It performs its function instantly and without requirement for adjustments.
The one-handed quick-release clamp is the quickest device for securing a work piece. These tools are specially designed for clasping workpieces; nevertheless, they are not correct for joining large surfaces and huge materials to one another. It is necessary not to forget that if you clamp work pieces over a long time, the clamping tension might be reduced. Consequently, it is recommended to replace them using parallel jaw clamps.
Quick Lever Clamps
The lever clamp is recognized for its easy clamping system. It has a durable all-metal body and robust construction, which eliminates worry about damage or wear, dissimilar to plastic one-handed clamps. Additionally, you have two kinds of these ideal and, in a lot of cases, unrivaled helpers at your disposal.
The range of lever clamps is especially notable for its compatibility with guide rails from favorable brands, like Makita, Stanely Black & Decker, Bosch, Dewalt, etc., as their jaws can be entered into a 12 mm guide T-slot. In addition, the quick lever clamps are convenient for securing work piece to a workbench. Providing ideal performance, and due to their plastic covers, stop damage to the clamped workpiece.
Face Clamps
The face clamp is a specialized device characterized by compatibility with assembly jigs and pocket holes. When these convenient devices are a part of your workshop, this type of clamp is a vital addition that you are going to probably find essential.
In addition, without these jigs you can benefit from the face clamp’s features, like its big clamping pads retaining workpieces straight. The smooth pressure management and the capacity to tweak it using a screw are especially useful. It is perfect for working with fragile materials without the risk of damaging a workpiece.
Pipe Clamps
In comparison to parallel clamps, pipe clamps provide a considerable advantage: you are only restricted by the length of the steel plumping pipe. When that is not enough, combine the two. Screwing one part of the jaws onto the steel pipe with a 27mm diameter and a G 3/4″ BSP thread, whereas the other jaw enters onto the opposing end of the pipe. The clamp is now ready for use. The jaws come equipped with feet that provide better stability and execution. The entire structure is made out of cast iron with clamping by a huge handle.
Spring Clamps
Spring clamps are not clamps in the conventional sense. It is adaptable and operates with a very light grip, making it almost like clothespins. Use it for fast and easy clamping of smaller work pieces, like differing slats or decorative moldings, in which high clamping pressure is not needed, and extreme pressures could cause damage.
Even with its gentle operation, the spring clamp is highly robust. The strong, heat-treated steel spring can withstand almost any use devoid of leaving pressure blemishes or causing other types of damage. The swiveling pads can help to better clamp work pieces, and the rubberized handle stops the device from slipping out of your hand.
